2.92mm (SMK) | Male | DC-40 GHz
PRODUCT P/N: 7005A-11
Planar blind mate crown, SMA, female coaxial connector with operating frequency range DC to 26.5 GHz. Planar connectors are typically used as a pair or set which is comprised of two connector subassemblies that have a common mating interface. Connectors are ideal for instruments, cables, components and accessories have superior electrical performance than what would be obtained by additional adapters.
Product Specifications
Electrical
| Frequency (GHz) | DC-40 |
| Peak Power (kW) | 1.35 |
| Attenuation Level (dB) | 0.45 |
| VSWR (max) | 1.35:1 |
Physical
| Connector Type | 2.92mm (SMK) |
| Connector Configuration | Male |
| Electrical Length | 18.0 ± 0.15mm |
| Type | Planar Blind Mate Crown |
| Brand Name | Weinschel |
