SMA | 0.5 - 2.5 GHz | High Current
PRODUCT P/N: 8820SFF1-02
Spectrum Control's Inmet bias tees combine quality and performance in a standard three-port network for high current applications. Inmet bias tees are manufactured for maximum performance and minimal disruption.
Product Specifications
Electrical
| Frequency (GHz) | 0.5 - 2.5 |
| Attenuation Level (dB) | 0.5 |
| RF to Bias Port Isolation (dB) | 20 |
| Current Amps | 7 |
| VSWR (max) | 1.40:1 |
| Voltage | 100 |
| Average Power (Watts) | 50 |
Physical
| Connector Type | SMA |
| Item Length (in) | 1.67 |
| Connector Configuration (AC + DC) | Female |
| Connector Configuration (AC) | Female |
| DC Input Connector | Solder post |
| Brand Name | Inmet |
