2.92mm (SMK) | DC-6 GHz | 175 W | 40 dB | Male/Male
PRODUCT P/N: 254-40-22
Spectrum Control offers Weinschel brand model 254, Low Intermodulation, 2.92mm (SMK). high power fixed attenuators with standard attenuation values to 40 dB with a frequency range to 6 GHz (DC) and a power rating up to 175 watts. These products are conduction cooled and have a low profile design, rugged design and free of solder joints.
Product Specifications
Electrical
| Frequency (GHz) | DC-6 |
| Average Power (Watts) | 175 |
| Attenuation Level (dB) | 40 |
| Impedance (Ohms) | 50 |
| VSWR (max) | 1.20:1 |
Physical
| Connector Type | 2.92mm (SMK) |
| Connector Configuration | Male/Male |
| Type | Convection Cooled |
| Specialty | Low Intermodulation |
| Brand Name | Weinschel |
