SMA | DC-18 GHz | 5 W | 30 dB | Female/Female
PRODUCT P/N: 18B5W-30F
Spectrum Control's Inmet brand, 5-watt power fixed attenuator with female/female SMA connector, 30 dB attenuation at 18 GHz. SMA fixed attenuators reduce the power levels of a signal by a predetermined amount. These products are a high-performing and durable passive coaxial solution essential to RF applications that will mate with MIL-STD-348 connector interface.
Product Specifications
Electrical
| Frequency (GHz) | DC-18 |
| Average Power (Watts) | 5 |
| Attenuation Level (dB) | 30 |
| Impedance (Ohms) | 50 |
| VSWR (max) | 1.35:1 |
Physical
| Connector Type | SMA |
| Connector Configuration | Female/Female |
| Type | Standard |
| Specialty | Traditional |
| Brand Name | Inmet |
