3.5mm | Female | DC-26.5 GHz
PRODUCT P/N: 1593
3.5mm, female broadband resistive power splitter with a frequency to DC-26.5 GHz and nominal insertion loss of 8.5 dB. Two outputs is included in a leveling loop or is used as a reference in a ratio system, for the purpose of providing an output signal whose source impedance is essentially matched to 50Ω.
Product Specifications
Electrical
| Frequency (GHz) | DC-26.5 |
| Average Power (Watts) | 1 |
| Amplitude Tracking (dB) | 0.25 |
| Nominal IL (dB) | 8.5 |
| Phase Tracking | 4 ± deg |
Physical
| Connector Type | 3.5mm |
| Connector Configuration | Female |
| Brand Name | Weinschel |
