N-Type | Female/Female | Inner
PRODUCT P/N: F7003
Weinschel F7003 inner dc block contains capacitance in-series with the center conductor to prevent the flow of dc current, while permitting RF power to flow without interruption. Its rugged constructed female/female type-N stainless steel connector has molded captive inner contact/bead assembly provides controlled and stable interface dimensions. Frequency range of 9 kHz - 18.6 GHz, 50V max. rating and 50 Ohm impedance.
Product Specifications
Electrical
| Frequency (GHz) | 9 kHz - 18.6 |
| VSWR (max) | 1.35:1 |
| Voltage | 50 VDC |
| Attenuation Level (dB) | 0.9 |
Physical
| Block Type | Inner |
| Connector Type | N-Type |
| Connector Configuration | Female/Female |
| Item Length (mm) | 50.80 |
| Item Diameter (mm) | 21 |
| Item Weight (mm) | 67 |
| Brand Name | Weinschel |
