SMA | 0.01 - 2.5 GHz | Standard
PRODUCT P/N: 8800SMF1-02
Spectrum Control's Inmet bias tees combine quality and performance in a standard three-port network for general purpose applications. Inmet bias tees are manufactured for maximum performance and minimal disruption.
Product Specifications
Electrical
| Frequency (GHz) | 0.01 - 2.5 |
| Attenuation Level (dB) | 1 |
| RF to Bias Port Isolation (dB) | 30 |
| Current Amps | 2.50 |
| VSWR (max) | 1.50:1 |
| Voltage | 100 |
| Average Power (Watts) | 5 |
Physical
| Connector Type | SMA |
| Item Length (in) | 1.77 |
| Connector Configuration (AC + DC) | Male |
| Connector Configuration (AC) | Female |
| DC Input Connector | Solder post |
| Brand Name | Inmet |
