Jam Mount | Pi circuit | 50,000 pF
PRODUCT P/N: FC-1AF35SPN4503
Electroless nickel finish, shell size 19 with 66 contacts,, jam mount, socket to PCB d-sub connector with a Pi filter circuit, and 50,000 pF capacitance value. Spectrum Control's filtered compact shell connectors provide an effective EMI filter that reduces the amount of real estate required within a product enclosure. Using our expertise in EMI filter design and manufacturing, these offer our planar-style filtered arrays.
Product Specifications
Electrical
| Filter Circuit | Pi |
| Capacitance Value | 50,000 pF |
| Capacitance Tolerance | ±25%, +100% |
| Dielectric Withstanding Voltage (V) | 500 |
| Working Voltage DC -55°C to +125°C (V) | 200 |
| Polarization | Normal |
Physical
| Connector Type | Jam Mount |
| Contact Type/Termination | Socket to PCB |
| Shell Size | 19 |
| Number of contacts | 66 |
| Contact AWG | 22 |
| Material/Finish | AL/ Electroless Ni |
| RoHS | No |
