2.92mm (SMK) | Female | DC-8.5 GHz
PRODUCT P/N: 1432-1
Weinschel brand coaxial termination with 2.92mm (SMK), female connector with DC-8.5 GHz, and 150 watt power. 2.92mm (SMK) connector per MIL-STD-348 interface dimensions - mate nondestructively with MIL-C-39012 connector. High Power, convection cooled termination has high quality connector with special high temperature support bead.
Product Specifications
Electrical
| Frequency (GHz) | DC-8.5 |
| Average Power (Watts) | 150 |
| VSWR (max) | 1.30:1 |
Physical
| Connector Type | 2.92mm (SMK) |
| Connector Configuration | Female |
| Type | High Power/Convection/Conduction Cooled |
| Specialty | Traditional |
| Brand Name | Weinschel |
